CW-100 Large Payload Long Endurance Hybrid Power Medium UAV
840min
Max Flight Time
135km/h
Cruising speed
5100m
Max Service Ceiling
25kg
Max Payload
Benefits and Features
With the continuous technical updates , our drones bring many actual benefits to our customers, including saving time and cost, getting more comprehensive data, keeping personnel safe.
product-detail
Outstanding Performance
3000m max take off attitude, 5100m max flight ceiling, 840min endurance, exposure delay within 10ms.
product-detail
VTOL
Vertical takeoff and landing, greatly reduce terrain dependence and adapts to most places.
product-detail
Large Payload Capacity
The CW-100 can carry up to 25kg payloads, which means it can use most mission equipment. This gives it a high degree of compatibility.
product-detail
Modular design
Set up or take down in a few minutes, get started quickly.
product-detail
Fully Auto
One-button take-off and land, safe and simple, landing accuracy within 10cm.
product-detail
Long Data Link
The maximum 200 km data link allows the CW-100 to easily perform a variety of long-range missions, such as automated surveillance.
product-detail
RTK and PPK Function
This means centimeter-level autonomous vertical landing and high-precision POS data.
product-detail
Super Adaptability
Fly in high altitude, high humidity, low temperature, and light rain condition with self-heating airspeed tube and battery.
Optional Payloads
JOUAV UAV can carry many types of mission payloads. You can choose different cameras according to the actual mission needs, including LiDAR system, industrial aerial camera, oblique camera system, gimbal system and SAR. Simple and flexible, multi-purpose.
PhaseOne iXM Series Camera
High-resolution medium format cameras for mapping and surveying
MG-150E EO/IR/LR Gimbal Camera
30x optical zoom and thermal imaging drone gimbal camera with 4km laser rangefinder
JoLiDAR-LR22S
JoLiDAR-LR22S is a lightweight and long-range laser scanner for UAV surveying.
Ground Control Stations
JOUAV offers handheld, portable and modular vehicle ground control station. You can choose different control devices according to the different environment and task.
TC-200 Handheld Ground Control Station
An all-in-one handheld UAV ground control station for controlling unmanned vehicles and payloads
GCS-303 Ground Control Station
A portable dual-screen ground control station to control drone flight, recovery, and payloads.
Supporting Software
JOUAV provides one-stop UAV products, including the supporting software needed for the task. You can use these software to plan a flight path, control and manage the drone, track and identify targets, and see video and geo-data information from the drone in real time.
Eagle Map Drone Surveillance Software
An intuitive software solution to deploy drones' security and surveillance operations.
FlightSurv Drone Mapping software
Cloud-based drone mapping software for flight planning, data collection, processing, and analysis.
Technical Specifications
Hardware
Fuselage
3.0m
Wingspan
5.2m
MTOW
110kg
Radio Link
100km / 200km(Optional)
DGPS
RTK/PPK
Payload
≤25kg
Flight Performance
Endurance
840min
Cruising Speed
135km/h
Wind Resistance
13.9-17.1m/s
Ceiling
5100m
Max Takeoff Altitude
3000m
V Positioning Accuracy
3cm
H positioning Accuracy
1cm+1ppm
* All performance data in the foregoing pages are theoretical values obtained by JOUAV® internal laboratories through tests carried out under particular conditions. For more information on the specific testing conditions, refer to the aforementioned product details. Actual performance may vary owing to differences in individual product configuration, software versions, application conditions, and environmental factors. All data is subject to actual usage.
Industry Applications
JOUAV drones widely used in mapping and geographic information, inspection, security monitoring, emergency and other fields of a variety of application scenarios.
Emergency Response
Application in the area with dense personnel and complex scenes security surveillance, CW VTOL UAV solution realize big area and long-term high-altitude real time surveillance.
Aerial Mapping & Surveying
Are you looking to add drones to your surveying services? Here is everything that you need to know about drone surveying.
Security & Surveillance
In this article, you will learn the benefits you can see with security drones, how to use drones for security surveillance, and more.
